legibility. Each sign are ideal for promoting your business, website or express your
opinions. It can be ideal for store, office, retail stores, schools, hospitals...
Checkout our customizable LED signs at your early convenience.
Product Features:
~ Programmable via Rs232 serial cable (or Usb serial cable)
~ Programmable via the supplied Remote control
~ Compatible with PC system (Windows 2000, XP, 7)
~ Time and date function; Schedule display function
~ Built-in programmable effects and graphics
~ Save up to 96 messages; Up to 23,000 characters in total
~ 12 type font styles; 25 types of display methods
~ 16 color combinations on the multicolor version
~ Multi-languages support in all countries
~ Housed in aluminum metal enclosure
~ Indoor or Outdoor use
~ Custom sizes upon request
Article Description:
| Letter Height | Display Array | Unit Dimension |
| 4.8" (122 mm) | 64L x 16H (pixels) | 528L x 160H x 40D (mm) |
| 4.8" (122 mm) | 80L x 16H (pixels) | 650L x 160H x 40D (mm) |
| 4.8" (122 mm) | 96L x 16H (pixels) | 772L x 160H x 40D (mm) |
| 4.8" (122 mm) | 128L x 16H (pixels) | 1015L x 160H x 40D (mm) |
| 4.8" (122 mm) | 160L x 16H (pixels) | 1260L x 160H x 40D (mm) |
| 4.8" (122 mm) | 192L x 16H (pixels) | 1503L x 160H x 40D (mm) |
| 4.8" (122 mm) | 240L x 16H (pixels) | 1869L x 160H x 40D (mm) |
| 4.8" (122 mm) | 256L x 16H (pixels) | 1991L x 160H x 40D (mm) |
| Letter Height | Display Array | Unit Dimension |
| 6.3" (160 mm) | 80L x 16H (pixels) | 880L x 240H x 100D (mm) |
| 6.3" (160 mm) | 96L x 16H (pixels) | 1040L x 240H x 100D (mm) |
| 6.3" (160 mm) | 128L x 16H (pixels) | 1360L x 240H x 100D (mm) |
| Letter Height | Display Array | Unit Dimension |
| 10.1" (256 mm) | 80L x 16H (pixels) | 1360L x 336H x 100D (mm) |
| 10.1" (256 mm) | 96L x 16H (pixels) | 1616L x 336H x 100D (mm) |
| 10.1" (256 mm) | 128L x 16H (pixels) | 2128L x 336H x 100D (mm) |
Note: 4.8" (Pitch 7.62mm) | 6.3" (Pitch 10mm) | 10.1" (Pitch 16mm)
Color Available:
Monchrome: Red, Yellow, Green, Blue, White, Purple
Tri-color: Red Green Yellow
Multi-color: Red Green Blue
Accessories Included:
1 x Remote Control ... Battery: 3Vdc (2xAAA)
1 x PC software CD (included manual)
1 x Rs232 Serial Cable
1 x Main Adaptor with AC Power Lead
2 x Mounting Brackets
Optional Devices:
~ USB/Rs232 converter
~ Rs485 serial cable
~ Ethernet (TCP/IP)
~ Wireless control
