legibility. Each sign are ideal for promoting your business, website or express your
opinions. It can be ideal for store, office, retail stores, schools, hospitals...
Checkout our customizable LED signs at your early convenience.
Product Features:
~ Programmable via PC (USB, Rs232, Rs485, TCP/IP, Wireless)
~ Compatible with PC system (Windows 2000, XP, 7)
~ Automatic detect LED screen; Available in 3-lines, 4-lines or more...
~ Time, date and temperature function; Schedule display function
~ Built-in programmable effects and graphics; Count-down function
~ Various brightness adjustment
~ Save up to 100 pages with different messages
~ Various types font styles and display methods
~ Various color combinations on the multicolor version
~ Multi-languages support in all countries
~ Housed in aluminum metal enclosure
~ Indoor or Outdoor use
~ Custom sizes upon request
Article Description:
| Pixel Pitch | Display Array | Unit Dimension |
| P 7.62 mm | 80L x 24H (pixels) | 695L x 263H x 80D (mm) |
| P 7.62 mm | 96L x 24H (pixels) | 817L x 263H x 80D (mm) |
| P 7.62 mm | 160L x 24H (pixels) | 1304L x 314H x 80D (mm) |
| P 7.62 mm | 96L x 32H (pixels) | 807L x 314H x 80D (mm) |
| P 7.62 mm | 128L x 32H (pixels) | 1045L x 314H x 80D (mm) |
| P 7.62 mm | 160L x 32H (pixels) | 1289L x 314H x 80D (mm) |
| Letter Height | Display Array | Unit Dimension |
| P 10.00 mm | 80L x 32H (pixels) | 885L x 395H x 80D (mm) |
| P 10.00 mm | 96L x 32H (pixels) | 1045L x 395H x 80D (mm) |
| P 10.00 mm | 128L x 32H (pixels) | 1365L x 395H x 80D (mm) |
| Letter Height | Display Array | Unit Dimension |
| P 16.00 mm | 96L x 32H (pixels) | 1611L x 587H x 80D (mm) |
| P 16.00 mm | 128L x 32H (pixels) | 2123L x 587H x 80D (mm) |
Note: Pitch 12mm | Pitch 20mm | Pitch 25mm | Pitch 31.25mm Upon request
Color Available:
Monchrome: Red, Yellow, Green, Blue, White
Tri-color: Red Green Yellow
Multi-color: Red Green Blue
Accessories Included:
1 x PC software CD (included manual)
1 x Rs232 Serial Cable
1 x Main Adaptor with AC Power Lead
2 x Mounting Brackets
Optional Devices:
~ USB/Rs232 converter
~ Rs485 serial cable
~ Ethernet (TCP/IP)
~ Wireless control
