office or home decoration. With their fit and finish they are very sharp and ex-
tremely well engineered with fully dimmable capabilities built-in right. They are
available with separate remote control that can be operated from up to 30 ft away.
An ethernet wire can be used to interlink up to 30 panels to 1 remote control.
Product Features:
~ Easy installation: LED light fixture & LED driver (included)
~ Low profile design: Its height is less than 3/4 inches
~ Sturdy aluminum housing with frosted acrylic plastic cover
~ Mounting hardware included
~ Panel thickness: 12.5 mm
~ High quality diffuser achieves even and soft light output
~ Incredibly bright (High power LED SMD 3014)
~ Perfect way to modernize your home or business by saving money on your
energy and maintenance costs
Article Description:
| Series | Color Temperature | Unit Dimension |
| Round | 2700K - 7000K | 7.1" x 7.1" | 180 x 180 (mm) |
| 9.4" x 9.4" | 240 x 240 (mm) | ||
| 11.8" x 11.8" | 300 x 300 (mm) | ||
| Series | Color Temperature | Unit Dimension |
| Sqaure | 2700K - 7000K | 7.9" x 7.9" | 200 x 200 (mm) |
| 11.8" x 11.8" | 300 x 300 (mm) | ||
| 23.6" x 23.6" | 600 x 600 (mm) | ||
| Series | Color Temperature | Unit Dimension |
| Rectangle | 2700K - 7000K | 7.9" x 23.6" | 200 x 600 (mm) |
| 11.8" x 23.6" | 300 x 600 (mm) | ||
| 11.8" x 47.2" | 300 x 1200 (mm) | ||
| 11.8" x 59.1" | 300 x 1500 (mm) | ||
| 23.6" x 47.2" | 600 x 1200 (mm) |
Color Rendering Index (CRI): Ra>70 (Cool White) | Ra>75 (Warm White)
Color Available:
2700-3500K (Warm White)
4000-4500K
5000-6000K
6000-6500K (Cool White)
6500-7000K
Power Factor: >0.95
Life Span: 50,000 hours
Voltage: Constant current LED driver: Input AC 85-265V
Protection Rating: CE | RoHS | FCC | IP20
Operating Temperature: -10° - +40°
Applications:
~ Commercial Lighting
~ Office Lighting
~ Warehouse Lighting
~ Supermarket Lighting
~ Large-scale Building
